Tektronix TDS 700D Technical Reference

Typical Characteristics
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
2–31
Table 2–16: Typical characteristics — Signal acquisition system (cont.)
Name Description
Effective Bits — TDS 694C Sample rate
The chart on the right gives the typical
Input frequency
10 GS/s
effective bits for a 9.2 divisions p–p
°
1 MHz 6.6 bits
sine wave input at 50 mV/div @ 25
°
C.
1 GHz
2 GHz
3 GHz
5.5 bits
4.5 bits
3.8 bits
Effective Bits — TDS 600C Input frequency Effective bits
(except TDS 694C)
The chart on the right gives the typical
effective bits for a 9-division p-p
sine-wave input, 50 mV/div, 10 ns/div
(5 GS/s), with a record length of 1000
points
98 MHz
245 MHz
490 MHz
990 MHz
6.3 bits
6.0 bits
5.5 bits
5.2 bits (TDS 680C & 684C only)
Effective Bits — TDS 520D & 724D Sample rate
The chart on the right gives the typical
Input frequency
1 GS/s 10 MS/s & HiRes
effective bits for a sine wave adjusted
1 MHz
6.8 bits 9.7 bits
to 9.2 divisions at 1 MHz, 50 mV/div @
25° C.
490 MHz
6.5 bits N/A
Effective Bits — TDS 540D & 754D Sample rate
The chart on the right gives the typical
Input frequency
2 GS/s 10 MS/s & HiRes
effective bits for a sine wave adjusted
1 MHz
6.8 bits 9.7 bits
to 9.2 divisions at 1 MHz, 50 mV/div @
25° C.
500 MHz
6.8 bits N/A
Effective Bits — TDS 714L Sample rate
The chart on the right gives the typical
Input frequency
500 MS/s 10 MS/s & HiRes
effective bits for a sine wave adjusted
1 MHz
6.8 bits 9.7 bits
to 9.2 divisions at 1 MHz, 50 mV/div @
25° C.
500 MHz
6.8 bits N/A
Effective Bits — TDS 580D, 784D & 794D Sample rate
The chart on the right gives the typical
effective bits for a sine wave adjusted
Input frequency
4 GS/s 10 MS/s & HiRes
to 9.2 divisions at 1 MHz, 50 mV/div @
°
1 MHz 6.6 bits 9.7 bits
25
°
C.
1 GHz
5.5 bits N/A
2 GHz – 6.5 divs (TDS 794D only) 4.5 bits N/A
Frequency Limit, Upper, 250 MHz
Bandwidth Limited
250 MHz
Frequency Limit, Upper, 20 MHz
Bandwidth Limited
20 MHz
