Tektronix TDS 700D Technical Reference

Performance Tests
1–30
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
TDS694C Test Record (cont.)
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS694C Performance Test MaximumOutgoingIncomingMinimum
CH2 200 mV Vert scale setting,
0 Div position setting, –5 V offset
–5.172 V __________ __________ –4.828 V
CH2 1 V Vert scale setting,
0 Div position setting, +2.5 V offset
+4.738 V __________ __________ +5.263 V
CH2 1 V Vert scale setting,
0 Div position setting, –2.5 V offset
–5.263 V __________ __________ –4.738 V
CH3 10 mV Vert scale setting,
–5 Div position setting, +.5 V offset
+0.5755 V __________ __________ +0.5845 V
CH3 10 mV Vert scale setting,
+5 Div position setting, –.5 V offset
–0.5845 V __________ __________ –0.5755 V
CH3 200 mV Vert scale setting,
0 Div position setting, +5 V offset
+4.828 V __________ __________ +5.172 V
CH3 200 mV Vert scale setting,
0 Div position setting, –5 V offset
–5.172 V __________ __________ –4.828 V
CH3 1 V Vert scale setting,
0 Div position setting, +2.5 V offset
+4.738 V __________ __________ +5.263 V
CH3 1 V Vert scale setting,
0 Div position setting, –2.5 V offset
–5.263 V __________ __________ –4.738 V
CH4 10 mV Vert scale setting,
–5 Div position setting, +.5 V offset
+0.5755 V __________ __________ +0.5845 V
CH4 10 mV Vert scale setting,
+5 Div position setting, –.5 V offset
–0.5845 V __________ __________ –0.5755 V
CH4 200 mV Vert scale setting,
0 Div position setting, +5 V offset
+4.828 V __________ __________ +5.172 V
CH4 200 mV Vert scale setting,
0 Div position setting, –5 V offset
–5.172 V __________ __________ –4.828 V
CH4 1 V Vert scale setting,
0 Div position setting, +2.5 V offset
+4.738 V __________ __________ +5.263 V
CH4 1 V Vert scale setting,
0 Div position setting, –2.5 V offset
–5.263 V __________ __________ –4.738 V
Analog Bandwidth
CH1 100 mV 424 mV __________ __________ N/A
CH2 100 mV 424 mV __________ __________ N/A
CH3 100 mV 424 mV __________ __________ N/A
CH4 100 mV 424 mV __________ __________ N/A
Delay Between Channels N/A __________ __________ 50 ps
