Performance Tests
1–72
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
H CHECK that the readout Ch2 Pk-Pk is between 40 mV and 60 mV,
inclusive, for the TDS 600C or is between 44 mV and 66 mV,
inclusive, for the TDS 500D/700D/714L.
H Enter voltage on test record.
4. Disconnect the hookup: Disconnect the cables from the channel inputs and
the rear panel outputs.
Equipment
required
One female BNC to clip adapter (Item 3)
Two dual-banana connectors (Item 6)
One BNC T connector (Item 7)
Two precision 50 W coaxial cables (Item 5)
One DC calibration generator (Item 9)
Prerequisites See page 1–17. Also, the oscilloscope must have passed Check
Accuracy For Long-Term Sample Rate, Delay Time, and Delta Time
Measurement on page 1–56.
1. Install the test hookup and preset the instrument controls:
a. Hook up test-signal:
H Connect one of the 50 W cables to CH 1. See Figure 1–21.
H Connect the other end of the cable just installed to the female
BNC-to-clips adapter. See Figure 1–21.
H Connect the red clip on the adapter just installed to the PROBE
COMPENSATION SIGNAL on the front panel; connect the black
clip to PROBE COMPENSATION GND. See Figure 1–21.
Check Probe
Compensator Output
