Tektronix TDS 754D User Manual

Operating Interface Maps
2–4
TDS 500D, TDS 600B, & TDS 700D User Manual
Front Panel Map — Right Side
Hardcopy, page 3–180
File System, page 3–175
Autoset, page 3–9
Help, page 3–199
Status, page 3–197
Selecting Channels,
page 3–12
Horizontal Controls,
page 3–21
Acquisition Modes, page 3–31
Cursor Measurements, page 3–138
Triggering, page 3–73
Delay Triggering, page 3–117
Edge Triggering, page 3–82
Logic Triggering, page 3–86
Pulse Triggering, page 3–99
Comm Triggering, page 3–113
Color, page 3–47
Display Settings,
page 3–40
Remote
Communication,
page 3–191
Vertical Controls,
page 3–16
Measurement System, page 3–126
Masks, page 3–148
Histograms, page 3–145
Saving and Recalling
Setups, page 3–165
Saving and Recalling
Waveforms, page 3–168
File System, page 3–175
Waveform Math,
page 3–206
Zoom, page 3–53
Probe Calibration,
page 3–158
Ground
Cursor
Measurements,
page 3–138
DPO,
page 3–59
