Tektronix TDS 784D Technical Reference

Typical Characteristics
2–34
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
Table 2–18: Typical characteristics — Triggering system (cont.)
Name Description
Width, Minimum Pulse and Rearm, for Logic
Triggering or Events Delay
For vertical settings > 10 mV/div and ≤ 1 V/div at the BNC input
Triggering type
Minimum pulse
width
Minimum re-arm
width
Minimum time
between channels
7
Logic Not Applicable 1 ns 1 ns
Events Delay 1 ns (for either + or
– pulse widths)
Not Applicable 2 ns
Width, Minimum Pulse and Rearm, for For vertical settings > 10 mV/div. and 3 1 V/div at the BNC input
Pulse Triggering
The minimum pulse widths and rearm
Pulse class
Minimum pulse
width
Minimum re-arm width
widths and transition times
8
required for
Glitch
1 ns 2 ns + 5% of Glitch Width Setting
Pulse-Type triggering.
Runt
2 ns 2 ns
Time-Qualified Runt 2 ns
TDS 694C: 1 ns
TDS 500D/700D/714L: 8.5 ns + 5% of width
setting
TDS 600C: 7 ns + 5% of Width Setting
TDS 694C: 8 ns + 5% of Width Setting
Width 1 ns 2 ns + 5% of Width Upper Limit Setting
Timeout 1 ns 2 ns + 5% of Width Upper Limit Setting
Slew Rate 600 ps
8
TDS 500D/700D/714L: 8.5 ns + 5% of delta
time setting
TDS 600C: 7 ns + 5% of Delta Time Setting
Setup/Hold Time Violation Trigger,
Minimum Clock Pulse Widths
For vertical settings > 10 mV/div and ≤ 1 V/div at the BNC input,
the minimum requirements are:
Minimum Pulse Width, Clock Active
9
Minimum Pulse Width, Clock Inactive
9
User Hold Time + 2.5 ns
10
User Hold Time + 2.6 ns
10
2 ns
Input Signal Sync Amplitude for Stable
Triggering, HDTV and FLEXFMT modes
(Option 05 Video Trigger)
All field selections: 0.6 division to 4 divisions
Jitter for HDTV mode
(Option 05 Video Trigger)
17 ns
p-p
Sync Width Flex Format and HDTV
modes (Option 05 Video Trigger)
min. 400 ns
Sync Duty Cycle, Flex Format and HDTV
modes (Option 05 Video Trigger)
min. 50 to 1
Hum Rejection
(Option 05 Video Trigger)
NTSC and PAL: –20 dB without any trigger spec deterioration. Triggering will continue
down to 0 dB with some performance deterioration.
