Resolution (by range)
200 0
0.10
2k0
10
20k0
100
200 k0
100 0
2 MO
1 k0
20 MO
10 k0
Continuity Check
Threshold
The beeper sounds if the resis-
tance of the circuit measured is
< 25 0 and turns off at > 200 0
Beeper Frequency 2 kHz
Overload Protection 600 VDCNACRms
Diode Test
Test Current
1.6 mA maximum
Test Voltage
3.3 V maximum open circuit
Overload Protection 600 VDCNACRms
Capacitance (DMM157)
Ranges
2 pF, 20 pF, 200 pF
Accuracy
± (1.9% reading + 5 digits)
Resolution (by range)
2 pF
1 nF
20 pF
10 nF
200 pF
100 nF
Overload Protection 600 VDCNACRms all ranges
Auto Power Off
The multimeter will automatically
shut off in about 30 minutes from
the last function or mode
change. The multimeter will turn
on again when another range is
selected or any key switch is
pressed.
WARRANTY
Tektronix warrants that this product will be free from
defects in materials and workmanship for a period of
three (3) years from the date of shipment. If any such
product proves defective during this warranty period,
Tektronix, at its option, either will repair the defective
product without charge for parts and labor, or will provide
a replacement in exchange for the defective product.
In order to obtain service under this warranty, Customer
must notify Tektronix of the defect before the expiration of
the warranty period and make suitable arrangements for
the performance of service. Customer shall be
responsible for packaging and shipping the defective
product to the service center designated by Tektronix,
with shipping charges prepaid. Tektronix shall pay for the
return of the product to Customer if the shipment is to a
location within the country in which the Tektronix service
center is located. Customer shall be responsible for
paying all shipping charges, duties, taxes, and any other
charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or
damage caused by improper use or improper or
inadequate maintenance and care. Tektronix shall not be
obligated to furnish service under this warranty a) to
repair damage resulting from attempts by personnel
other than Tektronix representatives to install, repair or
service the product; b) to repair damage resulting from
improper use or connection to incompatible equipment;
or c) to service a product that has been modified or
integrated with other products when the effect of such
modification or integration increases the time or difficulty
of servicing the product.
