Replaceable Parts
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-7
WVRRFP
-1 200-4874-00 1
COVER; TOP TO REMOTE FRONT PANEL,0.050 AL,SAFETY
CONTROLLED
-2 131-3295-00 1
CONN,RCPT,ELEC; HEADER,2 X 25,0.1 SPACING
389-3574-00 1
CIRCUIT BOARD; FRONT PANEL REGULATOR,SAFETY CONTROLLED
-3
671-9937-00 1
CIRCUIT BD ASSY; FRONT PANEL
REGULATOR,389-3574-00 WIRED,TESTED
-4 214-3903-00
-
SCREW,JACK; 4-40 X 0.312 LONG,0.188 H HEX HEAD STAND OFF,4-40
INT THD, X 0.312 THD EXT 4-40
-5
211-0721-00
-
SCREW,MACHINE; 6-32 X 0.375,PNH,STL,CDPL,T-15 TORX DR
-6 441-2295-00 1
CHASSIS,FRONT; REMOTE FRONT PANEL,0.050 AL
-7
441-2361-00 1
CHASSIS,MAIN; REMOTE FRONT
PANEL,,0.050 AL,W/HARDWARE,SAFETY CONTROLLED
5–16 WVR6020, WVR7020, and WVR7120 Waveform Rasterizers Service Manual
