The NOIRE range also offers more possibilities of customisation, for
example:
- self-learning of the code without acting on the receiver;
- customisation and protection of the code through a programmer;
- management of systems through dedicated software.
Fig. 1 Plug-in receiver TANGO SR / NOIRE SR
Fig. 2 Mini receiver TANGO RB / NOIRE RB
Fig. 3 Modular receiver TANGO R4 / NOIRE R4
Fig. 5
Transmitters TANGO 2 SLIM and TANGO 4 SLIM / NOIRE 2 and
NOIRE4
Fig. 6 Radio control opening
1. Connector for external connections
1-2 Power supply
3-4 Relay 1 output
5-6 Relay 2 output
7-8 Relay 3 output
9-10 Relay 4 output
11-12 Antenna
2. Jumper for power supply selection
3. Storage
4. Jumper for rolling-code selection
5. Button P1 and LED L1
6. Button P2 and LED L2
7. Button P3 and LED L3
8. Button P4 and LED L4
9. Connectors for inserting relay modules.
10. Antenna connector TANGO SR / NOIRE SR
GB
GENERAL DESCRIPTION
