Telcoma PASSO - TECHNICAL SPECIFICATIONS

46
46
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
GB
GB
PASSO M.U. Keypad Receiver
Power supply Vac/Vdc 12/24 12/24
Consumption (at 24Vac) mA 60 120
Relay contacts max. current A - 1
Relay contacts max. voltage Vac - 24
Connection line max. distance m 200
Transmission speed baud 38.400
No. of possible memorised codes nr. - 750
Max. number of keypad per receiver nr. 4 -
Operating temperature °C -10+70 -10+70
Protection class IP 53 20
Dimensions mm 102x43x34 79x48x21
