FATAL ERROR INDICATIONS AND ERROR CODE MESSAGES
Fatal errors are indicated by function LEDs 1–7, which are all flashing at the same time. Each fatal error
is identified by a code indicated by relay LEDs 1–5.
: LED is lit. : LED is off
Relay
LED1
red
Relay
LED2
red
Relay
LED3
red
Relay
LED4
red
Relay
LED5
red
Error code
message
Indicates
"Invalid PD
CPU3"
Invalid/ missing production
data in the CPUs
"Wrong SW
CPU4"
Incompatible software in the
CPUs
"Xapp init
failed"
Bad settings data
"No reply
CPU1/2"
No reply from CPU1 or CPU2
"Test mode" Receiver in test mode (no
error)
"IF cal. failed" Initialization of the radio
module failed
"Bad exp. in rly" Incompatible expansion board*
"Bad exp. in
can"
No CAN expansion board
found**
"SILerror" SIL error reported from CPU1
or CPU2
"Bad radio
module"
Incompatible radio module
"LML error" LML fatal error
"Bad binDat" Missing or bad binDat
"No binDat ID" No binDat ID in binDat
"LML bad
SWID"
Wrong target software ID in
binDat
"LML bad SW
ver"
Wrong target software version
in binDat
"LML bad cclml
ver"
Wrong cclml version in binDat
"LML buffer full" Buffer is full
* TG-R4-6, TG-R4-8 or TG-R4-10 models only.
** TG-R4-26, TG-R4-28, TG-R4-41, TG-R4-43 or TG-R4-45 models only.
- 14 -
