Sheet 3
1.Scope
This specifications is applicable to Express Luck Industrial LTD. 's 21.5" diagonal
module :"CX215LEDM"designed for TFT LCD TV.
1.1 Features
--Super Wide viewing angle
--Super High contrast ratio
--Super Fast response time
--High color saturation
--DE(Data Enable ) only mode
--LVDS Interface
--RoHS compliance
1.2 Application
TFT LCD TV
Multi-Media Display
1.3 General Specifications
1.4 Mechanical Specification
Note 1: Please refer to the"outline dimension" for more information of back and front outline dimensions.
EXPRESS LUCK INDUSTRIAL LTD.
Bezel Opening Area
Number of Pixels
Min Typ
Pixel Pitch
Pixel Arrangement
Transmissive Mode
Surface Treatment
Display Colors
495.6(H) x 292.2(V)
Production specification
Item
Driving Method
Active Area
Unit Note
Note 1
Specifications
a-Si TFT active matrix
476.64(H) x 268.11(V) mm
mm
pixel
mm
color
1920*1080
248.25(per one triad)x248.25
RGB horizontal Stripe
Normally Black
Anti-Glare,3H
Module
Size
Weight
Horizontal(H)
16.7M
Max
Vertical (V)
Depth(D)
Item
\
(TYP)+0.5
g\
(TYP)-0.5
1750
495.6
292.2
10.7
Note
-
1
mm
mm
mm
Unit
