LIST OF TABLES/INFORMATION
Table Page
1 Model 1200. 1800 & 1800 EXT Specifications 12
2 Model 2400, 3000 & 3600 Specifications 13
3 Environmental Operating Conditions 14
4 Recommended Breaker and Wire Size 14
5 Physical Dimensions 15
6 Recommended Breaker and Wire Size 27
7 37 Way Connector Pin Connection Details 29
8 Volt vs. Temperature Conversion 31
9 Serial Communication read/write Commands 35
10 Display Mnemonics and their Meaning 43
11 Normal Operating range Parameters 46
12 Alarms and Error Codes 48
13 Trouble Shooting Guide 50
14 Trouble Shooting Guide – Emerson compressor 56
15 Maximum Recommended Coil Surfaces 60
