Telemark 376 - Servicing; Motor Drive Assembly

5
SERVICING
Motor Drive Assembly
Ref Part# -8 Part# -9 Description Qty.
1 271-6030-8 271-6030-8 Soc. Head Cap Screw, #6-32 X 1/4" 9ea.
2 271-6130-8
271-6171-8
271-6130-8
271-6171-8
Soc. Head Cap Screw, #8-32 X 1-3/4"
Soc. Head Cap Screw, #10-32 X3/4"
4ea.
3 271-6150-8 271-6150-8 Soc. Head Cap Screw, #10-32 X 1/2" 3ea.
4 376-0085-1 Coupling 1ea.
5 376-0472-2 Motor Stand-off 3ea.
6 376-0620-1 376-0620-1 Pulley, 80 teeth 1ea.
7 376-9061-1 376-9061-1 Pulley, 20 teeth 1ea.
8 379-0203-1 379-0203-1 PCB, Indexer Opto Switch 1ea.
9 379-0204-1 379-0204-1 PCB, Indexer Switch Iso 1ea.
10 379-1001-2 379-1001-2 Switch Bracket 1ea.
11 379-1004-1 379-1004-1 Shutter Disk 1ea.
12 379-1005-2 379-1005-2 Shaft 1ea.
13 379-1006-2 379-1006-2 Feedthru Bracket 1ea.
14 376-1007-1 379-1007-1 Switch Cover ea.
15 379-1008-1 379-1008-1 Jackscrew 2ea.
16 379-1009-1 379-1009-1 Standoff 4ea.
17 376-9006-1 376-9006-1 Bushings 2ea.
18 376-9009-2
379-9009-2
376-9009-2
379-9009-2
Motor (376) or
Motor (379)
1ea.
19 376-9070-2 376-9070-2 Belt 1ea.
20 238-0160-1*
267-0160-1*
281-0160-1*
Motor Clamp, 238
Motor Clamp, 231, 267
Motor Clamp, 281
1ea.
21 281-0150-2* Gear, 24 teeth 1ea.
* Part of the Source assembly.
SERVICING 5-1
Telemark 376/379 Crucible Indexer
Figure 5-A
Assembly
