Technical specifications
Downstream signal path ( all values with the diplex filters)
Frequency range 47 / 54 / 70 / 85 / 108..1006 MHz
Return loss 18 dB
Gain 40.0 dB
Input attenuator control range 0...15 dB @ 1 dB
Input equaliser control range 0...20 dB @ 2 dB
Cable simulator 0 / -8 dB
Mid-stage slope 0 dB / 8 dB
Mid-stage gain selection 40.0 dB / 32.0 dB
Flatness ± 0.5 dB
Noise figure 7.0 dB
Output level, CTB CENELEC 42 ch 112.0 dBμV
Output level, CSO CENELEC 42 ch 114.0 dBμV
Output level, XMOD CENELEC 42 ch 111.0 dBμV
Upstream signal path (return module and diplex filters are installed into the CXE202)
Frequency range 5...30 / 42 / 50 / 65 / 85 MHzMHz
Return loss 18 dB
Gain 28.0 dB
Gain control range (output) 0... -15 dB @ 1 dB
Gain control range (input) 0 / -10 dB
Slope control range 0...15 dB @ 1 dB
Flatness ± 0.75 dB
Noise figure 5.0 dB
Output level, DIN 45004B 114.0 dBμV
General
Power consumption 14 W
Supply voltage 26...65 V AC, 180…255 V AC
Maximum current feed through 3.0 A / port
Input / Output connectors PG11 (several adaptors available)
Test point connectors F female (20 dB)
Dimensions (h x w x d) 140 (148) mm x 182 (210) mm x 84 mm
Weight 1.5 kg
Operating temperature -40...+55 °C
Class of enclosure IP54
EMC EN 60728-2
Additional EMC tests for RF ports ESD 4 kV / Surge 4 kV
All specifications are subject to change without notice
