LE910Cx mPCIe Hardware Design Guide
1VV0301510 Rev. 13 Page 13 of 73 2021-07-07
The sensitivity level has a deviation of approximately +/- <2dB
per model, device and channel because the level shows typical value.
LTE level is measured at BW 10M.
Mechanical Specifications
2.7.1. Dimensions
The overall dimensions of LE910Cx-mPCIe family are:
• Length: 50.95 mm, +0/-0.3mm
• Width: 30 mm, +0/-0.3mm
• Thickness : 3.2 mm, +/-0.15mm (Version with SIM holder : 4.62 mm, +/-0.15mm)
2.7.2. Weight
The nominal weight of the module;
With SIM holder: 10.3 grams
Without SIM holder: 9.1 grams
Temperature Range
Operating Temperature
Range
–20°C ~ +55°C
The module is fully functional(*) in all the temperature
range, and it fully meets the 3GPP specifications.
–40°C ~ +85°C
The module is fully functional (*) in the whole
temperature range.
However, there may be some performance deviations in
this extended range from the 3GPP requirements,
which means that some RF parameters may deviate
from the 3GPP specification on the order of a few dB.
For example: the receiver sensitivity or maximum
output power may be slightly degraded
Storage and non-operating
Temperature Range
–40°C ~ +105°C
Table 6:Temperature Range (*) Functional: the module is able to make and receive voice calls, data
calls, SMS and make data traffic.
