LE910Cx mPCIe Hardware Design Guide
1VV0301510 Rev. 13 Page 18 of 73 2021-07-07
Not Subject to NDA
Pin
Signal
I/O
Function
Type
Comment
1
WAKE_N O
Active low output signal used to wake up the
system from stand-by
3.3V
20
W_DISABLE_N I
Active low signal for wireless disabling
(Flight mode)
3.3V
22
PERST_N
I
Active low functional reset input to the card
3.3V
42
LED_WWAN_N O
Active low, open drain signal for WWAN LED
driving, used to provide module’s status
indication
3.3V
Reserved
3
Reseved
-
5
Reseved
-
6
Reserved
-
7
Reserved
-
11
Reserved
-
13
Reserved
-
16
Reserved
-
17
Reseved
-
19
Reseved
-
23
Reserved
-
24
Reserved
-
25
Reserved
-
28
Reserved
-
30
Reserved
-
31
Reserved
-
32
Reserved
-
33
Reserved
-
44
Reserved
-
45
Reseved
-
46
Reserved
-
47
Reserved
-
48
Reserved
-
49
Reserved
-
51
Reserved
-
Table 8: Pin-out PCI Express MiniCard Specification
