13. REFERENCE TABLE OF RF BANDS CHARACTERISTICS
Mode
Freq. Tx (MHz)
Freq. Rx (MHz)
Channels
Tx-Rx Offset
PCS 1900
1850.2 ~ 1909.8
1930.2 ~ 1989.8
512 ~ 810
80 MHz
DCS 1800
1710 ~ 1785
1805 ~ 1880
512 ~ 885
95 MHz
GSM 850
824.2 ~ 848.8
869.2 ~ 893.8
128 ~ 251
45 MHz
EGSM 900
890 ~ 915 935 ~ 960 0 ~ 124 45 MHz
880 ~ 890 925 ~ 935 975 ~ 1023 45 MHz
WCDMA 2100 – B1
1920 ~ 1980 2110 ~ 2170
Tx: 9612 ~ 9888
Rx: 10562 ~ 10838
190 MHz
WCDMA 1900 – B2
1850 ~ 1910 1930 ~ 1990
Tx: 9262 ~ 9538
Rx: 9662 ~ 9938
80 MHz
WCDMA 1800 – B3
1710 ~ 1785 1805 ~ 1880
Tx: 937 ~ 1288
Rx: 1162 ~ 1513
95 MHz
WCDMA AWS – B4
1710 ~ 1755 2110 ~ 2155
Tx: 1312 ~ 1513
Rx: 1537 ~ 1738
400 MHz
WCDMA 850 – B5
824 ~ 849 869 ~ 894
Tx: 4132 ~ 4233
Rx: 4357 ~ 4458
45 MHz
WCDMA 900 – B8
880 ~ 915 925 ~ 960
Tx: 2712 ~ 2863
Rx: 2937 ~ 3088
45 MHz
WCDMA 1800 – B9
1750 ~ 1784.8 1845 ~ 1879.8
Tx: 8762 ~ 8912
Rx: 9237 ~ 9387
95 MHz
WCDMA 800 – B19
830 ~ 845 875 ~ 890
Tx: 312 ~ 363
Rx: 712 ~ 763
45 MHz
TDSCDMA 2000 – B34
2010 ~ 2025 2010 ~ 2025
Tx: 10054 ~ 10121
Rx: 10054 ~ 10121
0 MHz
TDSCDMA 1900 – B39
1880 ~ 1920 1880 ~ 1920
Tx: 9404 ~ 9596
Rx: 9404 ~ 9596
0 MHz
LTE 2100 – B1
1920 ~ 1980 2110 ~ 2170
Tx: 18000 ~ 18599
Rx: 0 ~ 599
190 MHz
LTE 1900 – B2
1850 ~ 1910 1930 ~ 1990
Tx: 18600 ~ 19199
Rx: 600 ~ 1199
80 MHz
LTE 1800 – B3
1710 ~ 1785 1805 ~ 1880
Tx: 19200 ~ 19949
Rx: 1200 ~ 1949
95 MHz
LTE AWS – B4
1710 ~ 1755 2110 ~ 2155
Tx: 19950 ~ 20399
Rx: 1950 ~ 2399
400 MHz
LTE 850 – B5
824 ~ 849 869 ~ 894
Tx: 20400 ~ 20649
Rx: 2400 ~ 2649
45 MHz
LTE 2600 – B7
2500 ~ 2570 2620 ~ 2690
Tx: 20750 ~ 21449
Rx: 2750 ~ 3449
120 MHz
