LM940 Hardware Design Guide
1VV0301352 Rev. 18 Page 12 of 75 2022-01-04
CA_1A_3A_5A, CA_1A_3A_8A, CA_1A_3A_20A, CA_1A_3A_28A, CA_1A_5A_7A,
CA_1A_7A_20A, CA_1A_7A_28A, CA_3A_3A_8A, CA_3A_7A_8A, CA_3A_7A_20A,
CA_3A_7A_28A, CA_1A_3C, CA_3A_7B, CA_3A_7C, CA_3C_5A, CA_3C_7A,
CA_3C_20A, CA_5A_40C, CA_7B_28A, CA_7C_28A, CA_28A_40C, CA_40D
Table 2: Generic Image Frequency Bands
2.2.1.2. AT and T Image Frequency Bands and CA Combinations
LTE 2DL Carrier Aggregation Combinations
CA_2A_4A, CA_2A_5A, CA_2A_12A,2A_29A, CA_2A_30A, CA_2A_66A, CA_4A_5A,
CA_4A_12A, CA_4A_29A, CA_4A_30A, CA_5A_30A, CA_5A_66A, CA_12A_30A,
CA_12A_66A, CA_30A_29A, CA_30A_66A, CA_66A_29A, CA_2A_2A, CA_4A_4A,
CA_66A_66A, CA_2C, CA_5B, CA_12B, CA_66B, CA_66C
CA_2A_2A_5A, CA_2A_2A_12A, CA_2A_4A_5A, CA_2A_4A_12A, CA_2A_5A_30A,
CA_2A_5A_66A, CA_2A_12A_30A, CA_2A_12A_66A, CA_ 2A_29A_30A, CA_4A_4A_5A,
CA_4A_4A_12A, CA_4A_5A_30A,4A_12B, CA_4A_12A_30A, CA_4A_29A_30A,
CA_5A_30A_66A, CA_5A_66A_66A, CA_5A_66C, CA_12A_30A_66A, CA_12A_66A_66A
Table 3: AT and T Image Frequency Bands
2.2.1.3. Verizon Image Frequency Bands and CA Combinations
CA_2A_4A, CA_2A_5A, CA_2A_13A, CA_2A_66A, CA_4A_5A,4A_13A, CA_5A_66A,
CA_13A_66A, CA_2A_2A, CA_4A_4A, CA_66A_66A, CA_5B, CA_66B, CA_66C
2A_2A_5A, CA_2A_2A_13A, CA_2A_4A_5A, CA_2A_4A_13A, CA_2A_5A_66A,
CA_2A_13A_66A, CA_4A_4A_5A, CA_4A_4A_13A, CA_5A_66A_66A, CA_13A_66A_66A,
CA_66A_66C, CA_2A_66C, CA_5A_66C, CA_13A_66C
Table 4: Verizon Image Frequency Bands
2.2.1.4. Sprint Image Frequency Bands and CA Combinations
CA_25A_25A, CA_25A_26A, CA_26A_41A, CA_41A_41A, CA_41C
CA_26A_41C, CA_41A_41C, CA_41D
Table 5: Sprint Image Frequency Bands
