Teltonika DPH200 - TECHNICAL SPECIFICATIONS

Teltonika © 2008, GSM Desktop Phone DPH200 User Manual v1.02
20
8 TECHNICAL SPECIFICATIONS
GSM Interface
Quad-Band GSM 850 / 900 / 1800 / 1900 MHz.
Output power:
class 4 (2 W) for EGSM 850/900.
class 1 (1 W) for GSM 1800/1900.
Memory
Address book up to 240 entries (SIM dependant)
SMS memory up to 30 (SIM dependant)
Call memory: 10 last dialed, 10 last received, 10 last missed
Power supply
Mains adaptor: 100 - 240 V AC / 5.2V 1A
Built in lightning protection
Battery: NiMH 3.6V 1600 mAh
Power consumption when talking 2W (peak)
Power Consumption stand by (100mW)
Battery charging time 120 hours
Talking time: 90 minutes
Temperature & humidity
Operation 0
0
to 55
0
C
Storage temperature -20
0
to 80
0
C
Humidity 10% to 90%
Storage humidity 5% to 95%
Dimensions / weight
Approx. 220 x 170 x 65 mm
Weight: Approx. 920 g
Other
External omni directional antenna (SMA)
Antenna Gain 2dBi
Port for FW update - RJ45 (UART)
