______________________(GB)____________________ 9 - Keep work area clean. Cluttered areas invire injuries.
10 - Avoid damaging Start Plus system. Use only as
INSTRUCTION MANUAL
specified in this manual.
11 - Observe work area conditions. Do not use in damp or
wet location. Do not expose to rain. Keep work area well
GENERAL INFORMATION
lighted.
A truly portable starter with battery. Ideal for anyone needing
a starter . Applications include boats, cars, trucks, tractors,
12 - Do not places this unit in direct sunlight , direct heat or
generators and more.
moisture.
Fully compatible with any 12 volt or 24 volt starter system.
The START PLUS uses MAINTENANCE-FREE SEALED
13 - Keep children away. Children must never be
BATTERIES so that the unit can be placed anywhere in any
allowed in the work area. Do not let them handle
position without the danger of acid spills.
machines, tools, or extension cords.
14 - Store idle equipment. When not in use, the starter must
Save this Manual
be stored in a dry location to inhibit rust. Always lock it
You will need the manual for the safety warnings and
up and keep out of reach of childern.
precautions, operating and maintenance procedures, parts
list and specifications.
Keep the manual in a safe and dry place for future reference.
15 - Dress properly. Do not wear loose clothing
or jewelry as they can be caught in moving parts.
Protective, electrically non conductive clothes and
nonskid footwear are recommended when working.
READ ALL INSTRUCTION BEFORE USING THIS
Wear restrictive hair covering to contain long hair.
STARTER!
16 - Repair should be carried out by experts only otherwise
it may cause considerable danger for user.
SAFETY WARNINGS AND PRECAUTIONS
17 - Replacement parts and accessories. When carrying
Warning: When using this starter, basic safety
out maintenance, use only identical spare parts (see
precautions should always be followed to reduce the
spare parts list). Use of any other parts will void the
risk of personal injury and damage to equipment.
warranty.
18 - Do not overreach. Keep proper footing and balance at
all times. Do not reach over or across electrical cables
1 - Wear eye protection. When working on or
or frames.
19 - Maintain this starter with care. Inspect starter cords
around lead-acid always wear eye protection.
periodically and if damaged have them repaired by an
autorized technician.
2 - Avoid contact with battery acid. If splashed,
20 - Check for damaged parts. Before using this starter any
immediatly wash affected area with clean water.
part that appears damaged should be carrefully
Continue washing area until medical help arrives.
checked to determine that it will operate properly and
perform its intended function. Check for alignment and
binding of moving parts, any broken parts or mounting
3 - Connect cables to proper polarities. Connect
fixtures, and any other condition that may affect proper
black cable to negative ground and red cable to positive
operation. Any part that is damaged should be properly
battery terminal.
repaired or replaced by a qualified technician.
- Use this starter in well ventilated areas. Do not attempt
to jump start vehicle around flammable gases or
OPERATION
liquids.
4 - Do not allow the black and red clamps to touch. If
Warning: Electrical shock can use death or injury. Avoid
this happens, clamps or other metal objects may melt.
touching exposed conductors of electricity.
WARNING! In order to prevent damage caused by
accidental contact, disconnect the positive cable
The START PLUS system is designed for use with vehicle or
before putting the starter away. Never ever close the
boats. You will not need a host vehicle or 230VAC power
clamps on the metal case of the appliance!
supply.
5 - ONLY FOR 12 or 24 VOLT SYSTEMS! Use correctly
You can also use this system as a portable power source of
only on boats and vehicles with 12 or 24 volt electrical
12 VDC in remote areas or emergencies.
systems.
6 - For emergency use only. Do not use this starter in the
To use the START PLUS system to start your vehicle:
place of a vehicle battery. Only use to start your
- Make sure the ignition switch of the vehicle or boat to be
vehicle.
started is not switched on. Connect the red clamp to the
7 - Avoid working alone. If an accident happens, an
positive terminal on the vehicle’s battery.
assistant can bring help.
- Connect the black clamp to a non moving metal part of the
engine, not to the negative terminal.
- Turn the ignition switch of the vehicle or boat to ON. Wait
8 - Avoid electrical shock. Use extreme caution
for about a minute. Switch the boat or vehicle to the start
when clamping around uninsulated conductors or bus
position for no more then 5 to 6 seconds. If the vehicle or
bars. Prevent body contact with grounded surfaces
boat engine does not start, wait at least for 3 minutes
such as pipes, radiators and cabinet enclosures when
before retrying.
testing voltages.
Caution: Never allow the red and black clamps to touch
