Page 17 of 44
1.5.3 Manual Mode Menu
1.5.4 Auto-Tuning Mode
Press and hold key 5 seconds to activate Auto-Tuning Mode
Note:
§ Using Manual, Auto-Tuning, Calibration modes will break the control loop and change some of the
previous setting data. Make sure that the system is allowable to apply these modes.
§ The flow chart shows a complete list of all parameters. For actual application, the number of
available parameters will vary depending on the setup and model of controller, and will be less
than that shown in the flow chart.
§ The user can select up to 8 parameters to put in the user select menu by using the SEL1~SEL8
parameters in the setup menu.
1.5.5 Calibration Mode
Press key for 2 seconds or longer (not more than 3 seconds) then release it to enter calibration Mode.
Press Key for 5 seconds to perform calibration.
Press key 5 Sec To execute the selected default program
2 sec minimum,3 sec maximum
To Next Page
