Specification
TEC-2400
TEC-9400
TEC-8400
TEC-8450
TEC-7400
TEC-4400
TEC-6400
Sensor Break Detection
Sensor open for Thermocouple, RTD and mV inputs, Sensor short for RTD input ,
Below 1mA for 4-20mA input, Below 0.25VDC for 1 - 5VDC input, Not available for other inputs.
Sensor Break Response Time
Within 4 seconds for Thermocouple, RTD and mV inputs, 0.1 second for 4-20mA and 1 - 5VDC inputs.
Remote Set Point Input
Type
Linear Current, Linear Voltage
Range
-3mA to 27mA, -1.3VDC to 11.5VDC
Accuracy
±0.05 %
Remote Set Point
Not Available
Not Available
Available
Available
Available
Available
Not
Available
Input Impedance
Current: 2.5Ω, Voltage:1.5MΩ
Resolution
18 Bits
Sampling Rate
1.66 Times/Second
Maximum Rating
280mA maximum for Current Input, 12VDC Maximum for Voltage Input
Temperature Effect
±1.5µV/°C for Voltage Input , ±3.0µV/°C for Current Input
Sensor Break Detection
Below 1mA for 4-20mA input, Below 0.25VDC for 1 - 5VDC input, Not available for other inputs.
Sensor Break Responding
Time
0.1 Second
Event Input
Number of Event Inputs
1
2
6
6
2
6
1
Logic Low
-10VDC minimum, 0.8VDC maximum.
Logic High
2VDC minimum, 10VDC maximum
Functions
See availability table
CT Input
CT Type
CT98-1
Accuracy
±2%of Full scale Reading,±0.2A
Input Impedance
294Ω
Measurement Range
0 to 50AAC
Output of CT
0 to 5VDC
CT Mounting
Wall (Screw) Mount
Sampling Rate
1 Time/Second
Output 1 /Output 2
Type
Relay, Pulsed Voltage, Linear Voltage, or Linear Current
Relay Rating
2A, 240V AC,200000 Life Cycles for Resistive Load
Pulsed Voltage
Source Voltage 5VDC,Current Limiting Resistance 66Ω
Linear Output Resolution
15 Bits
Linear Output Regulation
0.02% for full load change
Linear Output Settling Time
0.1 Sec (Stable to 99.9%)
Isolation Breakdown Voltage
1000 VAC
Temperature Effect
±0.01% of Span/ °C
Load Capacity of Linear Output
Linear Current: 500Ω max., Linear Voltage: 10KΩ min
Alarm
Relay Type
Form A
Maximum Rating
2A,240VAC,200000 Life Cycles for Resistive Load
Alarm Functions
Dwell Timer, Deviation Low, Deviation High, Deviation Band Low, Deviation Band High, Process High, Process Low
Alarm Mode
Latching, Hold, Normal, Latching/Hold
Dwell Timer
0.1 to 4553.6 Minutes
Data Communication
Interface
RS-485
Protocol
Modbus RTU (Slave Mode)
Address
1 to 247
Baud Rate
2.8KBPS to 115.2KBPS
Parity Bit
None, Even or Odd
Stop Bit
1 or 2 Bits
Data Length
7 or 8 Bits
Communication Buffer
160 Bytes
Analog Retransmission
Output Signal
4-20mA, 0-20 mA,0 - 10VDC
Resolution
15 Bits
Accuracy
±0.05% of Span ± 0.0025% / °C

Tempco TPC-1000 Specifications
