10.1. Factory test mode: t
In factory test mode the controller activates the various control board output signals one by one, with
a pause between each step. When the test sequence is complete the controller automatically returns
to normal mode.
10.2. Commissioning mode: c
During commissioning mode delay times are reduced:
• Minimum On-Off time (‘Run’-time) 90 seconds
• Minimum Off-On time (‘Off’-time) 20 seconds
• Minimum On-On time (‘Cycle’-time) 1 minute
• Cooling to heating change-over time 1 minute
• Heating to cooling change-over time 1 minute
Commissioning mode ends automatically after 30 minutes. It is also possible to manually end
commissioning mode either by cycling mains power off and on again, or by again using the
pushbutton and select option ‘c’. When commissioning mode ends the controller returns to normal
mode.
10.3. Compressor selection mode: E
IMPORTANT: Always ensure the correct compressor model is selected!
If an incorrect selection is made it is likely to cause the unit to malfunction and could lead to
permanent damage to the compressor.
Unit model
Compressor model
Display
OSA 171 RLS
YPV030LT-3X9 Copeland
P1-Y030L
OSA 171 RLT
YPV030LT-4X9 Copeland
P3-Y030Lt
OSA 211 RLT
YPV038LT-4X9 Copeland
P3-Y038L
OSA 251 RLT
YPV050ST-4X9 Copeland
P3-Y050S
OSA 351 RLT
AVB66FT2MT SCI
P3-AUb66
10.4. Supply-air temperature control option: Y
OSA + ISD installations can provide automatic control of the supply air temperature. Available
selections are:
• 0: Disable supply air temperature control (default value)
• 1: Enable supply air temperature control
