TemperZone UC8 - DIP Switch Settings; Fan Behavior and Expansion Valve Arrangement Settings; Electronic Expansion Valve Type and Master;Slave Selection; Model Identification via DIP Switches

Temperzone UC8 Operation, OSA models with inverter, issue 1
Page 7 of 27
2. DIP switch settings
Switch
Function
1
OFF
ON
Indoor fan behaviour
Indoor fan speed may vary from the thermostat request.
Indoor fan speed follows the thermostat request.
Note: Thermostat fan settings and protection functions can override the selections
above.
2
OFF
Reserved
Do not select any other setting.
3
OFF
4
ON
Outdoor fan type
Outdoor fan 0-10V control signal on output V1.
5
OFF
6
ON
Reserved
Do not select any other setting.
7
ON
8
OFF
Expansion valve arrangement
Single- or parallel- EEV.
9
OFF
ON
OFF
ON
10
OFF
OFF
ON
ON
Electronic expansion valve type
How to recognise the valve type
Dunan DPF series
Zhe Jiang Sanhua DPF series
Carel E2V series
Reserved, do not select
removable black coil
non-removable metal coil
removable red coil
-
11
OFF
12
OFF
Master / slave selection
Stand-alone unit / master unit.
13
OFF
14
OFF
15
OFF
16
OFF
Models OSA and OPA.
