Tempest POWER BLOWER - Honda Direct Drive;Electric Blower Parts

SCHEMATIC REFERENCE 2003
DD16-H-5.5 DD18-H-5.5 DD21-H-6.5 DD 24-H6.5
ITEM # DISCRIPTION PART # PART # PART # PART #
1 FRONT GRILL 230-027 230-032 230-029 230-030
1A GRILL EMBLEM 400-040 400-028 400-029 400-030
1B NEOWASHER 120-004 120-004 120-004 120-004
1C GRILL BOLT 100-002 100-002 100-002 100-002
2 BLADE GAS 260-030 260-075 260-019 260-026
2 BLADE ELECT. 260-069 260-075 260-019 260-021
2 BLADE VSF 260-030 260-068 260-071 N/A
2 BLADE VSM 260-074 260-075 260-019 N/A
2A BUSHING
See page 8.6 See page 8.6 See page 8.6 See page 8.6
2B SHAFT EXT. KEY call call call call
2C SHAFT EXT. 170-004 170-004 170-004 170-004
3 SHROUD 725-024 705-001 705-002 705-003
3A FRONT TRIM 410-002 410-002 410-003 410-004
4 REAR GRILL 230-028 230-023 230-021 230-022
4A NYLOCK 130-003 130-003 130-003 130-003
4B NEOWASHER 120-004 120-004 120-004 120-004
4C GRILL BOLT 100-002 100-002 100-002 100-002
5 FRONT FOOT 580-006 580-006 580-006 580-006
6 FRAME GAS/ELEC
600-137/600-216 600-037 600-192 600-103
7 ROCKER LTCH 600-159 600-159 600-159 600-159
8 HANDLE GAS/ELEC
600-077/600-217 600-198 600-156 600-199
9 NYLOCK BSHNG 120-002 120-002 120-002 120-002
10A LEFT LEG 600-162 600-166 600-196 600-170
10B RIGHT LEG 600-163 600-167 600-195 600-171
MUFFLER 190-012 190-012 190-028 190-028
11 GAS ENGINE 350-004 350-004 350-016 350-016
11A SHFT KEY GAS 460-022 460-022 460-022 460-022
12 ELECT MOTOR *360-038 *360-027 *360-027 *360-027
12 VSF ELC MTR 360-036 360-036 360-036 N/A
12 VSM ELC MTR 360-041 360-042 360-042 N/A
12A SHFT KEY ELECT. call call call call
12B ELEC MTR SPCR 600-102 600-102 600-102 600-102
13 STEP BAR 600-138 600-181 600-182 600-183
14 STEP SPRING 300-019 300-019 300-019 300-019
15 REAR SPR. ASSY 600-001 600-001 600-001 600-001
16 REAR FOOT PAD 580-007 580-007 580-007 580-007
17 WHEEL BOLT 100-002 100-002 100-002 100-002
18 WHEEL 240-003 240-003 240-003 240-003
*Explosion proof, two speed or variable speed electric motor replacement, call customer service.
12" electric and 36" electric or direct drive please see Briggs schematic.
HONDA POWERED DIRECT DRIVE / ELECTRIC BLOWER P
A
8.2
