TEMPEST TECHNOLOGY CORPORATION
4708 N. BLYTHE AVENUE
FRESNO, CA 93722
800-346-2143
559-277-7577 FAX: 559-277-7579
TEMPEST POSITIVE PRESSURE POWER BLOWER
PARTS LIST
DO NOT REMOVE PULLEYS, THIS WILL VOID WARRANTY
CONTACT FACTORY FOR PROPER PROCEDURE
BELT-DRIVE UNITS
ITEM DESCRIPTION ITEM DESCRIPTION ITEM DESCRIPTION
1 FRONT GRILL 7 REAR GRILL 14 NYLOCK BUSHING
1A GRILL EMBLEM 7A NYLOCK 15A LEFT LEG
1B NEOWASHER 7B NEOWASHER 15B RIGHT LEG
1C GRILL BOLT 7C GRILL BOLT 16 ENGINE
2 FAN BLADE 8 BEARING ASSY 16A MUFFLER
2A BUSHING 8A SHAFT KEY 17 STEP BAR
3 BELT 9 FRONT FOOT 18 STEP SPRING
4 TOP PULLEY 10 FRAME 19 REAR SPRING ASSY.
5 SHROUD 11 GAS TANK 20 REAR FOOT PAD
5A FRONT TRIM 12 ROCKER SPR. LATCH 21 WHEEL BOLT
6 ENGINE PULLEY 13 HANDLE ASSY. 22 WHEEL
