Tempest POWER BLOWER - Briggs Blower Parts List

BRIGGS POWERED DIRECT DRIVE / ELECTRIC BLOWER PARTS
SCHEMATIC REFERENCE 2003
EB12 DD21-B-5.5 DD 24-B5.5 DD36-B-5.5
ITEM # DISCRIPTION PART
#
PART
#
PART
#
PART
#
1 FRONT GRILL 230-015 230-029 230-030 230-017
1A GRILL EMBLEM 400-039 400-029 400-030 400-041
1B NEOWASHER 120-004 120-004 120-004 120-004
1C GRILL BOLT 100-002 100-002 100-002 100-002
2 BLADE GAS N/A 260-019 260-026 260-013
2 BLADE ELECT. 260-028 260-019 260-021 260-012
2 BLADE VSF 260-030 260-068 260-071 N/A
2 BLADE VSM 260-074 260-075 260-019 N/A
2A BUSHING N/A 160-019 160-019 160-036
2B SHAFT EXT. KEY call call call call
2C SHAFT EXT. 170-004 170-004 170-004 170-004
3 SHROUD call 705-002 705-003 call
3A FRONT TRIM 410-002 410-003 410-004 N/A
4 REAR GRILL 230-016 230-021 230-022 230-018
4A NYLOC
K
130-003 130-003 130-003 130-003
4B NEOWASHER 120-004 120-004 120-004 120-004
4C GRILL BOLT 100-002 100-002 100-002 100-002
5 FRONT FOOT 580-006 580-006 580-006 580-006
6 FRAME 600-117 600-192 600-103 600-034
7 ROCKER LTCH N/A 600-159 600-159 N/A
8 HANDLE ASSY 600-077 600-156 600-199 N/A
9 NYLOCK BSHNG 120-002 120-002 120-002 120-002
10A LEFT LEG 600-162 600-196 600-170 600-081
10B RIGHT LEG 600-163 600-195 600-171 600-082
* MUFFLE
R
N/A 190-039 190-039 190-039
11 GAS ENGINE N/A 350-024 350-024 350-024
11A SHFT KEY GAS N/A 460-022 460-022 460-022
12 ELECT MOTOR *360-018 *360-027 *360-027 *360-027
12 VSF ELC MTR 360-036 360-036 360-036 N/A
12 VSM ELC MT
R
360-041 360-042 360-042 N/A
12A SHFT KEY ELECT. call call call call
12B ELEC MTR SPCR 600-102 600-102 600-102 600-102
13 STEP BAR 600-138 600-182 600-183 600-138
14 STEP SPRING 300-019 300-019 300-019 300-019
15 REAR SPR. ASSY 600-001 600-001 600-001 600-001
16 REAR FOOT PAD 580-007 580-007 580-007 580-007
17 WHEEL BOLT 100-002 100-002 100-002 100-002
18 WHEEL 240-001 240-003 240-003 240-003
*Explosion proof, two speed, variable speed electric motor replacement, call customer service.
3/24/2003
