F97CMN and G97CMN: Installation, Start-up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
21
(SW1-5 and SW4-3 set to OFF, except as indicated. See notes 1 and 2.)
Unit Size: 0602120 Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches SW2-3 SW2-2 SW2-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1735 1735 1725 1715 1700 1685 1665 1650 1625 1605
CF Switches SW3-3 SW3-2 SW3-1
Low-Clg Default: OFF OFF OFF 540 525 525 520 540 See note 4
Cooling Airflow
(SW2)
Low-Cooling
Airflow (SW3)
OFF OFF ON 540 525 525 520 540 See note 4
OFF ON OFF 680 725 725 720 720 See note 4
OFF ON ON 925 915 910 895 900 890 875 865 860 855
ON OFF OFF 1070 1075 1080 1070 1080 1075 1055 1045 1030 1020
ON OFF ON 1215 1245 1235 1220 1220 1210 1200 1195 1185 1175
ON ON OFF 1380 1385 1395 1390 1395 1390 1380 1365 1355 1340
ON ON ON 1735 1735 1725 1715 1700 1685 1665 1650 1625 1605
Maximum Clg Airflow
2
1955 1950 1940 1925 1905 1885 1855 1815 1745 1685
CF Switches SW3-3 SW3-2 SW3-1
Cont. Fan Default: OFF OFF OFF 540 525 525 520 540 See note 4
Continuous Fan
Airflow (SW3)
OFF OFF ON 540 525 525 520 540 See note 4
OFF ON OFF 680 725 725 720 720 See note 4
OFF ON ON 925 915 910 895 900 890 875 865 860 855
ON OFF OFF 925 915 910 895 900 890 875 865 860 855
ON OFF ON 925 915 910 895 900 890 875 865 860 855
ON ON OFF 925 915 910 895 900 890 875 865 860 855
ON ON ON 925 915 910 895 900 890 875 865 860 855
Heating (SW1)
Maximum Heat Airflow
3
1080 1085 1095 1090 1095 1085 1070 1055 1045 1030
Intermediate Heat Airflow
3
685 725 730 725 730 See note 4
Minimum Heat Airflow
3
560 555 555 550 565 See note 4
Unit Size: 0801714 Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches SW2-3 SW2-2 SW2-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1055 1065 1080 1075 1065 1050 1045 1035 1025 1005
CF Switches SW3-3 SW3-2 SW3-1
Low-Clg Default: OFF OFF OFF 520 505 505 495 490 See note 4
Cooling Airflow
(SW2)
Low-Cooling
Airflow (SW3)
OFF OFF ON 520 505 505 495 490 See note 4
OFF ON OFF 665 685 680 660 665 See note 4
OFF ON ON 885 895 905 900 900 895 885 875 860 845
ON OFF OFF 1055 1065 1080 1075 1065 1050 1045 1035 1025 1005
ON OFF ON 1245 1245 1255 1255 1260 1255 1250 1235 1220 1185
ON ON OFF 1245 1245 1255 1255 1260 1255 1250 1235 1220 1185
ON ON ON 1245 1245 1255 1255 1260 1255 1250 1235 1220 1185
Maximum Clg Airflow
2
1520 1485 1450 1415 1375 1335 1300 1265 1225 1190
CF Switches SW3-3 SW3-2 SW3-1
Cont. Fan Default: OFF OFF OFF 520 505 505 495 490 See note 4
Continuous Fan
Airflow (SW3)
OFF OFF ON 520 505 505 495 490 See note 4
OFF ON OFF 665 685 680 660 665 See note 4
OFF ON ON 885 895 905 900 900 895 885 875 860 845
ON OFF OFF 885 895 905 900 900 895 885 875 860 845
ON OFF ON 885 895 905 900 900 895 885 875 860 845
ON ON OFF 885 895 905 900 900 895 885 875 860 845
ON ON ON 885 895 905 900 900 895 885 875 860 845
Heating (SW1)
Maximum Heat Airflow
3
1520 1485 1450 1415 1375 1335 1300 1265 1225 1190
Intermediate Heat Airflow
3
755 745 755 755 765 See note 4
Minimum Heat Airflow
3
620 625 630 620 610 See note 4
Table 7 – Cooling
4
and Heating Air Delivery - CFM (Bottom Return
5
With Filter) (Continued)
