Tempur
®
Sleeptracker-AI
®
System
For TEMPUR ERGO
®
SMART
System Components
Sleeptracker-AI
®
Sleep Monitoring System Model STS-60 / STS-60A :
- One Sleeptracker-AI
®
Processor Units
- One or two Sleeptracker-AI
®
Sensors*
Quick Start Card with QR code
Safety and Warranty Information
*Note: the number of sensor units included depends on the particular
TEMPUR ERGO
®
SMART POWERED BY SLEEPTRACKER-AI
®
size purchased.
Specifications
Sleeptracker-AI
®
Sleep Monitoring System Model STS-60 / STS-60A:
- Input Power: 5V DC, 1.5A
WLAN:
IEEE802.11a/b/g/n/ac
Wi-Fi frequency range:
2.4 GHz ISM Bands 2.412-2.472 GHz
5.15-5.25 GHz (FCC UNII-low band) for US/Canada and Europe
5.25-5.35 GHz (FCC UNII-middle band) for US/Canada and Europe
5.47-5.725 GHz for Europe 5.725-5.825 GHz (FCC UNII-high band) for US/
Canada
Wi-Fi AP channel:
802.11b:
USA, Canada and Taiwan – 1 ~ 11
Most European Countries – 1 ~ 13
802.11g:
USA and Canada – 1 ~ 11
Most European Countries – 1 ~ 13
802.11n:
USA and Canada – 1 ~ 11
Most European Countries – 1 ~ 13 802.11a:
USA – 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136,
140, 149, 153, 157, 161, 165
Output Power (Board Level Limit):
2.4G
Min Typ Max Unit
11b (11Mbps) @EVM<35% 14 16 18 dBM
11g (54Mbps) @EVM≦-27 dB 12 14 16 dBM
11n (HT20 MCS7) @EVM≦-28 dB 11 13 15 dBM
11n (HT40 MCS7) @EVM≦-28 dB 10 12 14 dBM
5G
Min Typ Max Unit
11a (54Mbps) @EVM≦-27 dB 11 13 15 dBm
11n (HT20 MCS7) @EVM≦-28 dB 8 10 15 dBm
11n (HT40 MCS7) @EVM≦-28 dB 8 10 12 dBm
11ac (VHT20 MCS8) @EVM≦-30 dB 8 10 12 dBm
11ac (VHT40 MCS9) @EVM≦-32 dB 7 9 11 dBm
11ac (VHT80 MCS9) @EVM≦-32 dB 6 8 10 dBm
Bluetooth
®
Standard:
Bluetooth 4.2+Enhanced Data Rate (EDR)
Bluetooth 5 support
Bluetooth frequency range:
2402MHz~2483MHz
Output Power:
Min Typ Max Unit
BDR 0 2 4 dBm
EDR -4 -1 1 dBm
Low Energy 0 2 4 dBm
Certifications:
- FCC Part 15B, FCC Part 15C
- ISED ICES-3(B)/NMB-3(B), RSS-Gen, RSS-102, RSS-210
© 2023 Tempur Sealy International, Inc.
All rights reserved. Tempur-Pedic
®
is a registered trademark of Tempur Sealy
International, Inc. TEMPUR ERGO
®
SMART is a trademark of Tempur Sealy
International, Inc.
© 2005–2023 Fullpower Technologies, Inc.
All rights reserved. U.S. and international patents granted and pending.
Sleeptracker-AI
®
is a trademark of Fullpower Technologies, Inc., registered in
the U.S. and other countries.
The Bluetooth
®
word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Tempur Sealy International,
Inc. is under license. Other trademarks and trade names are those of their
respective owners.
For assistance visit our web site: www.sleeptracker.com
Services and app availability are subject to change at any time, may not be
available in all areas and may require separate subscriptions.
This product is not a medical device and should not be used to diagnose or treat any
medical condition.
3
