English
01
Power on the CPE
Option 1: Use the PoE injector
Option 2: Use the power adapter
Option 3: Use other PoE power-supply device
If your CPE has a DC power jack, use the included power adapter
to power on the CPE.
Use the included power adapter to avoid damage to the CPE.
Tips
This option is available for the CPE that supports standard PoE power supply. You
can check whether the CPE supports standard PoE power supply on the package
box or the CPE’s Specifications page on www.tendacn.com.
Tips
Reset
12V 1A
GND
PoE/LAN
IEEE 802.3af/at-compliant
power-supply device
PoE
CAT5 or better Ethernet cable (≤100 m) recommended
CPE (Example: O6)
PoE/LAN
CPE (Example: OS3)
PoE/LAN1
PoE
PoE injector
Power socket
CAT5 or better Ethernet cable recommended.
To Next Page
