3
Integrated big capacity independent
transferring/receiving FIFO buffering area.
Adopting high integration and high
performance single chipset solution.
Supports BootROM, able to realize
RPL/PXE while inserting the appointed
BootROM.
Abundant driving software supported,
almost supports all the normal operating
systems including WIN NT4.0, WIN98SE,
WIN ME, WIN 2000, WIN XP, NOVELL
SERVER/CLIENT, LINUX2.2X/2.4X/2.6X,
MAC OS and Free BSD etc.
1.3 Specifications
Main Features
Protocol
IEEE802.1p IEEE802.1Q
IEEE802.3 IEEE802.3u
IEEE802.3ab IEEE802.3x
BUS Type 32bit 33/66MHZ PCI BUS
Network
Interface
RJ45
I/O Address System auto assign
Disconnected
(IRO)
System auto assign
Half/Full
Duplex
Transfer
Rate
10/20Mbps
100/200Mbps
2000Mbps
Operating
Temperature
0℃~45℃ (32 F ~112 F)
Operating
Humidity
10%-90% (non condensing)
Consumption 5 Voltage power input from
