Tenda W150D Technical Specifications

11N Wireless
USB Adapter
WHAT THIS PRODUCT DOES
BENEFITS
TECHNICAL SPECIFICATIONS
Create a high speed network to enjoy and share
streaming, music, digital photos and files from
multiple PCs simultaneously
Multiple access modes like PPPoE, PPPoA,MER,
IPoA and Bridge
Simple but powerful web management
Advanced security network by WPS, WPA and WPA2
IP/MAC filter against unauthorized access
150Mbps
Reset, WPS, WLAN, Power
2.412GHz~2.484GHz
DC 12V,1A
0ºC ~ 40ºC
10 to 90% Noncondensing
-40 to 70ºC
5% ~ 90% RH non-condensing
160mmX102mmX30mm (6.3"X4.0"X1.2")
0.89Kg
All For Better NetworkAll For Better Network
All For Better NetworkAll For Better Network
Shenzhen Tenda Technology Co., Ltd.
Contact us
Address:Tenda Industrial Park, No. 34-1, Shilong Rd.,Shiyan Town,
Bao’an District, Shenzhen, P.R. China 518108
Tel: 0086.755.2765.7180 Fax: 0086.755.2765.7178
E-mail: sales@tenda.com.cn Http: www.tenda.cn
Copyright statement
Obligation-free statement
Dynamic IP, Static IP, PPPoE, PPPoA, PPTP, L2TP, IPoA, Bridge
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
1 detachable 3dBi omni-directional antenna
1 Power Port,1 RJ11 Port, 4 10/100Mbps RJ45 Ports
PACKAGE CONTENTS
150M Wireless ADSL2+ Modem Router
Power Adapter
Quick Installation Guide
CD-ROM (User Guide included)
Network Cable
Telephone Line*2
Voice Splitter
MINIMUM REQUIREMENTS
Internet Explorer 5.5 or Firefox 1.0
Network Adapter
Max.Wireless SpeedMax.Wireless Speed
InterfaceInterface
ButtonsButtons
FrequencyFrequency
Power RatingPower Rating
Operating TemperatureOperating Temperature
Operating HumidityOperating Humidity
Storage TemperatureStorage Temperature
Storage HumidityStorage Humidity
Dimension (WXDXH)Dimension (WXDXH)
Gross WeightGross Weight
Connection typeConnection type
Encryption modeEncryption mode
AntennaAntenna
CertificateCertificate
CE,RoHS
Wireless
N
11N Wireless
PCI Adapter
11N Wireless
Notebook Adapter
Ethernet Switch
Computer
Tenda is the registered trademark of Shenzhen Tenda
Technology Co. LTD in CHINA and certain other countries.
Copyright © 2007 Shenzhen Tenda Technology Co. LTD
All rights reserved. Other brands and product name
are trademarks or re gistered tra demarks of their
respective holders.
The maximum per formance for wireless is derived from IEEE Standard 802.11 specifications. Actual
performance can var y, including lower wireless network capacity, data throughput rate, range and
cove rage. Performance depends on many factors, conditions and variables, i ncluding distance f rom
the access point, vo lume of netwo rk traffic, building materials and construction, operating system
used, mix of wireless products used, inter ference and other adve rse conditions.
Check the product package and co ntents for specific features supp orted. Specifications are subject to
change without notice.
W322PV2.0W322PV2.0
Model No.: W150D
IEEE 802.11b/g/n,802.3 &802.3u, Classical IP and ARP over ATM,
PPPoA, PPPoE, ITU G.992.1, ITU G.992.2 ,ITU G.992.3, ITU G.992.5,
ANSI T1.413 Issue 2
Standards Standards

Tenda W150D Specifications

General

VPN support	PPPTP, L2TP, Ipsec
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Bandwidth	2.4 GHz
Interface	LAN, WAN, WLAN
USB ports quantity	0
Networking features	Ethernet, Fast Ethernet
Maximum data transfer rate	0.1 Gbit/s
Minimum system requirements	Internet Explorer 6.0 / Firefox 1.0
Supported data transfer rates	10/100Mbit/s
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Supported network protocols	IPoE, PPPoE, PPPoA, IPoA, DHCP server
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Antennas quantity	1
Antenna gain level (max)	5 dBi
Web-based management	-
Ethernet LAN (RJ-45) ports	4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	9 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FC, CE, RoHS
Cables included	LAN (RJ-45)
Product color	White
LED indicators	DSL, LAN, Link, Power, WAN, WLAN

Weight and Dimensions

Depth	171.95 mm
Width	118.97 mm
Height	31 mm
Weight	- g
