3
Display
• The primary temperature display reports the current or last IR temperature read
until the 8-second hold time elapses.
• The secondary temperature display reports a choice of maximum, minimum,
difference between maximum and minimum temperature.
• You can display the maximum and minimum temperature anytime the display is on.
• The MAX, MIN temperatures are constantly calculated and updated while the
trigger is pressed.
• After the trigger is released, all readings are held for 8 seconds.
Emissivity setting display.
Laser on symbol.
SCAN Active SCAN.
HOLD Display Hold.
MAX MIN Maximum or Minimum Value.
Low Battery symbol. Appears when the battery charge is <4.5V.
Backlight indication.
o
C /
o
F Celsius / Fahrenheit.
HIGH
LOW
Sound alarm for the upper and lower temperature limit.
