EN OPERATION
6
B2 331081 (7--04)
OPERATING THE MACHINE
1. Ensure the height of suction head is approximately
75mm above surface (or adjusted to meet expected
debris size). If necessary, turn the adjustment
handle to change the suction head height. Refer to
Fig. 4.
FIG. 4
2. T urn on the key switch (B). Refer to Fig. 5.
A
B
FIG. 5
4. Push the machine to the area to be cleaned.
5. Push the machine and squeeze the vacuum trigger
to start collecting debris. Refer to Fig. 6.
NOTE: Squeeze the vacuum trigger only when collecting
debris. Prolonged or unnecessary use of vacuum trigger
reduces the life of the battery.
FIG. 6
6. Release the trigger handle when through collecting
debris.
7. If necessary, use the broom to push debris out from
behind obstructions and away from curbs.
OPERATING THE FUSE RESET BUTTON
This machine is equipped with a 60 amp. resettable fuse
and a fuse reset button.
1. If the machine should cease operating due to the
fuse, press the fuse reset button and restart
machine. Refer to Fig. 7.
NOTE: Call for service if the fuse should continuously to
stop the machine from operating.
FIG. 7
2. Continue cleaning operations.
OPERATING THE WORKLAMP
1. Use the toggle switch to operate the worklamp.
Refer to Fig. 8.
FIG. 8
