MACHINE SPECIFICATIONS
Model 52H
Maximum shearing capacity, mild steel 16 gauge / 1,6mm
Maximum shearing capacity, stainless steel 20 gauge / 1,0mm
Maximum cutting length 52-1/4 in. / 1327mm
Back gauge range 30 in. / 762mm
Front gauge range 37 in. / 940 mm
Floor space, gauges in position 60 x 80 in. / 1524 x 2032 mm
Overall dimensions, less gauges, LxWxH 61 x 25 x 42 in. / 1550 x 915 x 1067 mm
Strokes per minute, full length 60
Maximum operating pressure 1450 psi / 98.6 atmos.
Motor-230/460v, 3 phase, 60Hz, 1745 RPM 3 hp
Amp Draw of 3 phase motor 3hp 8.6 230 volt 3 phase
Motor-230, 1phase, 60Hz, 1725 RPM 3 hp 230 volt 1 phase
Amp Draw of 1 phase motor 3hp 10.7 amps
Shipping weight 1300 lbs. / 590 kg
APPROXIMATE SHEARING, BENDING AND FORMING
CAPCITIES FOR VARIOUS MATERIALS COMPARED TO MILD STEEL
Mild Steel Capacity 20ga. 18ga. 16ga. Mild Steel Capacity 20ga. 18ga. 16ga.
NON-FERROUS METALS FERROUS METALS
Aluminum Iron-dead soft 20ga. 18ga. 16ga.
1100-0, 2024-0 .070 .090 .125 Steel low carbon
5052-0. 6061-T4 .070 .090 .125 1074, 1095 C.R. Spring Steel 24ga. 22ga. 20ga.
2024-T3, 5052-H34 .048 .063 .090 Hot Rolled 20ga. 18ga. 16ga.
5086-H36, 6061-T6 .048 .063 .090 Low carbon Cold Rolled 20ga. 18ga. 16ga.
Copper and Alloys Stainless Steel Annealed 24ga. 22ga. 20ga.
Electrolytic Copper 18ga. 16ga. 14ga. OTHER MATERIALS
Bronze Commercial 18ga. 16ga. 14ga. Plastics
Brass 70-30 18ga. 16ga. 14ga. ABS Compounds .120 .150 .200
Nickel Alloys Polycarbonate .075 .105 .125
Inconel 600 24ga. 22ga. 20ga. Printed Circuit Boards
Monel R405 24ga. 22ga. 20ga. Copper-Clad
Nickel 200A Annealed 24ga. 22ga. 20ga. Epoxy Laminate .086 .115 .150
Zinc as Rolled 20ga. 18ga. 16ga.
Approximate Gauge Equivalents
Gauge 28 26 24 22 20 18 16 14 12 11 10
Inches .015 .018 .024 .030 .036 .048 .060 .075 .105 .120 .135
Millimeters .38 .46 .61 .76 1.00 1.25 1.60 2.00 2.70 3.05 3.50
