8
Model 52H Parts List
INDEX
NO. 52H DESCRIPTION QTY. NO. 52H DESCRIPTION QTY.
1 10151 TABLE 1 84 05543 NUT, CYLINDER BRKT. 8
2 10152 CUTTER BAR 1 85 62551 HYDRUALIC PUMP 1
3 10153 HOLDDOWN 1 86 62552 HYDRUALIC VALVE 1
4 10051 R.H. SIDE PANEL 1 87 62553 PRESSURE GAUGE 1
5 10052 L.H. SIDE PANEL 1 88 62554 SOLENOID VALVE 1
6 10053 FRONT ARM EXT. 2 89 62555 MOTOR 1
7 05055 SCREW, FRONT ARM EXT. 4 90 62556 COUPLING, MOTOR 1
8 05673 WASHER, FRONT ARM EXT. 4 91 10302 STUD, TURNBUCKLE 2
9 10054 SPRING, HOLDDOWN 2 92 10303 CLEVIS, FOOT PEDAL 2
10 10164 STUD, HOLDDOWN SPRING 2 93 05544 PIN, FOOT PEDAL CLEVIS 2
11 05880 NUT, HOLDDOWN STUD 2 94 10304 PIN, PEDAL BAR 2
12 05907 CAP NUT, HOLDDOWN STUD 2 95 62590 HYDRUALIC CYLINDER 2
13 05060 SCREW, HOLDDOWN 2 96 62591 CLEVIS, CYLINDER 2
14 05673 WASHER, HOLDDOWN SCREW 2 97 62592 PIN, CYLINDER 4
17 10055 SCALE, L.H. TABLE 1 98 10305 GUARD PANEL, FRONT 1
18 10056 SCALE, R.H. TABLE 1 99 05545 SCREW, FRONT PANEL GUARD 6
19 05021 SCREW, TABLE SCALE 4 100 10306 PANEL GUARD, REAR 1
20 05639 WASHER, TABLE SCREW 4 101 05546 SCREW, REAR PANEL GUARD 4
21 05327 SET SCREW, TABLE ADJ. 2 102 05547 SCREW, MOUNTING 12
22 05035 SCREW, TABLE LOCK 2 103 05548 WASHER, MOUNTING 12
23 05670 WASHER, TABLE LOCK SCREW 4 104 05549 NUT, MOUNTING 12
24 05075 BOLT, TABLE 4 105 10307 SUPPORT PLATE, MOUNTING 1
25 05676 WASHER, TABLE BOLT 4 106 45061 FOOT SWITCH 1
26 05925 NUT, TABLE 4 107 45062 CORD, FOOT SWITCH 1
27 10155 KNIFE, UPPER 1 108 45063 CONTROL PANEL 1
28 05033 SCREW, UPPER KNIFE 9 109 45064 POWER SWITCH 1
29 05670 WASHER, UPPER KNIFE 18 110 62557 HYDRAULIC HOSE ASSEMBLY 4
30 10156 KNIFE, LOWER 1 112 62558 OIL TANK ASSEMBLY 1
31 05035 SCREW, LOWER KNIFE 8 113 10309 MOUNTING ASSEMBLY 2
32 05670 WASHER, LOWER KNIFE 16
33 05246 SET SCREW, LOWER KNIFE ADJ. 8
34 05759 NUT, LOWER KNIFE ADJ. 8
35 10064 SHIM, C’BAR 2
36 05249 SCREW, C’BAR SHIM 6
37 05762 NUT, C’BAR SHIM SCREW LOCK 6
38 10157 STRAIGHTENER ROD, C’BAR 1
39 05673 WASHER, STRAIGHTENER ROD 3
40 05787 NUT, STRAIGHTENER ROD 3
41 10165 ADJ. SCREW, STRAIGHTENER ROD 1
44 05331 SET SCREW, BACKGAUGE ROD 2
45 05331 SET SCREW, HOLDDOWN LOCK 2
46 10302 SPRING, FOOT PEDAL 2
47 15053 SPRING GUIDE 2
48 15057 CAP, SPRING 4
49 15055 STUD, SPRING 2
50 05787 NUT, SPRING STUD 8
51 10069 LINKAGE BOLT, C’BAR 2
52 05827 NUT, LINKAGE BOLT, C’BAR 2
54 05826 NUT, STUD 8
55 10071 TURNBUCKLE 2
57 06354 PIN, LINKAGE, MOUNTING 2
62 10058 ROD, BACKGAUGE 2
63 10163 STOP, BACKGAUGE 1
64 10065 R. EXT. BAR, BACKGAUGE 1
65 10066 L. EXT. BAR, BACKGAUGE 1
66 10059 ADJ. BLOCK, BACKGAUGE 2
67 10060 ADJ. DIAL, BACKGAUGE 2
68 10075 ADJ. SCREW, BACKGAUGE 2
69 05762 NUT, ADJ. SCREW 2
70 10061 LOCK SCREW, BACKGAUGE 4
71 10062 ADJ. BRKT. BACKGAUGE 2
72 05027 SCREW, EXT. BAR 2
73 05325 SWIVEL BOLT 3
74 05765 NUT, SWIVEL BOLT 2
75 10159 STOP, FRONT MATERIAL 1
76 10074 “T”-NUT 3
77 05938 WING NUT, “T”-NUT 3
78 10063 BEVEL GAUGE 1
80 10158 BACKGAUGE ASSEMBLY 1
81 10301 CYLINDER BRKT. 2
82 05541 SCREW, CYLINDER BRKT. 8
83 05542 WASHER, CYLINDER BRKT. 8
To Next Page
