Tense TPM-04 User Manual

-4-
7- Introduction of Screen:
1 - Indicates the unit of the value.
2 - Indicates which phase the value belongs to .
Indicates that the values shown are minimum.
(Period: 2 seconds.)
Indicates that the values shown are average.
(Period: 5 minutes.)
Specified that the indicated active energies are imported.
Specified that the indicated active energies are exported.
Specified that the indicated reactive energies are inductive.
3 - Indicates displayed values. V-voltage, I-current, F-frequency, S-apparent power, P-active power,
PF-power factor, FI-cosine phi, THD-I-total current harmonics, THD-V- total voltage harmonics,
Q- reactive power.
Specified that the indicated reactive energies are capacitive.
Specified that the indicated reactive energies are inductive.
Specified that the indicated reactive power are capacitive.
Out2: Relay 2 is pulled.
(Short circuit)
Out1: Relay 1 is pulled.
(Short circuit)
Out1: Relay 1 is released.
(Spen circuit)
Out2: Relay 2 is released.
(Open circuit)
-3-
1
2
3
2
L1
3
L2
1
L3
THD-IPF
I
Q
S
kW h
VAk h
Hz
kW h
VA rk h
Hz
kW h
VA rk h
Hz
%
kA
%
kA
%
kA
Σ
P
Σ
+Q
Σ
-Q
Indicates that the values shown are maximum.
(Period: 2 seconds.)
Indicates that the values shown are demand.
(Period: 15 minutes.)
r
Out1
Din1
-P
-P
-Q
-Q
+Q
+Q
+P
+P
Out2
2
2
Out1
Out1
Out2
Out2
Total active energy.
Σ
P
Total inductive reactive energy.
Σ
+Q
Total capacitive reactive energy.
Σ
-Q
New Pass
Time
CTR VTR
kV THD-V
Din1: There is voltage(1).
Din1: There is no voltage(0).
Din1
Din1
This button enters menu/parameter. It records the changes of parameters and remove
from parameter.
ESC:
SET:
DOWN:
RIGHT:
Press this button while in menu to exit the menu without saving the values.
When this key is pressed while not in the menu, the screen always shows figure-3.
This button enables to fast progress between the values that are measured out of menu.
Changes the value while inside the parameters in the menu.
This button allows to progress by displaying the measured values outside the menu together
with the details. It allows navigation between parameters when pressed in menu.
In the parameter, it allows to transition between steps and parameters.
8- Introduction of Buttons:
