First operation
18 V-04/2018
Notice
The calibration cable included with the device can also be used
for a function check. Use of the calibration cable alone does not
start the calibration process.
► For mounting the sensor units, use the flange holes (1) on the bottom of
the housing.
For secure mounting on a bumper without a special LAP-TEQ holder, you can
use the optional TEQSAS LAP-TEQ magnetic holder. The sensor must be
bolted firmly to the flying frame or secured by suitable means against falling.
4.3 First operation
The sensor units are calibrated at the factory so that the base plate has to be
oriented downward. To use the sensor unit in a different position, it must be
recalibrated. Four positions are possible (90° grid on the longitudinal axis), see
page 24.
For the firs
t-time use the base plate must be positioned downward.
