43
4 MACHINE DESCRIPTION / CONTROLS
4.7 Electric Attachment Control
Attachments for the PT-100 are controlled by pressing various buttons on the
machines joysticks. Most attachments are controlled hydraulically, but some
require both hydraulic and electrical inputs. The 4 buttons on the left joystick
(4.7-1) send electrical current to the receptacle on the lift arms (4.7-2). Approved
attachments that require electrical inputs have a matching receptacle.
Note: The electrical receptacle is not necessarily compatible with other brands.
Use only approved attachments for proper function.
4.7-1
4.7-2
