Terex R190T Service Manual

Note:
If any of the safety signs shown in this section are missing or damaged, contact
your dealer to obtain a replacement.
Key (continued)
11. Belt/fan entanglement hazard
12. Skin (oil) injection hazard
13. Crush hazard (lift arm brace)
14. Crush Hazard (Lift arms)
15. Fall hazard / rollover Hazard / read operator’s manual
16. Crush / fall hazards
17. Crush (run over) hazard
18. Clean undercarriages notice
19. Tie down location
20. Burn hazard
2 SAFETY
13
Burn Hazard
Contact with hot surfaces can
cause burns.
• Do not touch hot
components!
• Allow the machine to
cool thoroughly prior to
servicing.
2030-601
Entanglement Hazard
Rotating parts can cause personal injury.
Keep away from fan and belt while the
engine is running. Stop engine before
servicing.
2030-600
CRUSH HAZARD
Contact with moving machine can
result in death or serious injury.
Keep clear of moving machine.
2030-593
Read Operator’s Manual
Read and understand the operator’s manual
and all safety signs prior to operating or
maintaining the machine.
Improper operation or maintenance can re-
sult in serious injury or death.
No Riders
Fall Hazard
Falling from a machine can result in serious
injury or death
.
Carry loads low. Load unload and turn on
level ground. Travel on inclines with heaviest
end of machine uphill.
Rollover/Ejection Hazard
Serious injury or death can result.
2030-598
Fasten Seat Belt
Crush Hazard
Rollover can crush and result in serious injury or death.
Do not use the bucket/attachment as a work platform.
Fall Hazard
Falling can result in serious injury or death.
2030-596
Crush Hazard
Death or serious injury can result
from contact with moving lift arm or
attachment.
Keep clear of lift arms and
attachments.
2030-592
Injection Hazard
Escaping fluid under pressure can
penetrate skin, causing serious injury.
• Relieve internal pressure before
disconnecting any line or fitting.
• Keep away from leaks or pinholes.
• Use cardboard to check for leaks.
Fluid injected into skin must be surgi-
cally removed within a few hours by a
doctor familiar with this type of injury
or gangrene will result.
2030-602
20
11
12
14
15
16
17
19
Crush Hazard
Death or serious injury can result
from contact with moving lift arm or
attachment.
Install lift arm brace prior to servicing.
2030-594
13
Inspect undercarriages daily for
accumulation of debris. If debris
is present, clean thoroughly with
a pressure washer. If debris is
allowed to build up, it can cause
premature component wear and
decrease machine performance.
2085-253
NOTICE
18
R160T / R190T US O&M
0404-490 2014-06
