Terex T25I and T45I Super Quiet Generator 39
Operating Instructions and Parts Manual
November 2007
REV B
FASTENER STAINLESS STAINLESS SAE GRADE SAE GRADE SAE GRADE SAE GRADE
SIZE STEEL* STEEL* 5 PLATED 5 PLATED 8 PLATED 8 PLATED
UNF NYLOK (METRIC NYLOK (METRIC NYLOK
& NUT 8.8) NUT 10.9) NUT
UNC
#6 (10-12) (8.5-10) (14-16)
#8 (20-22) (17-19) (25-28)
#10 (26-32) (22-27) (40-45)
1/4" (75-94) (64-80) 7-9 12-14
5/16" 12-Nov 14-Dec 15-17 23-26
3/8" 20-22 22-24 28-34 45-50
7/16" 31-33 32-35 40-45 70-75
1/2" 43-45 45-50 75-85 70-80 100-110 95-105
9/16" 57-63 60-65 80-100 75-95 145-160 135-150
5/8" 92-104 100-105 130-170 125-165 175-205 165-195
3/4" 128-135 140-150 220-240 205-225 380-420 365-405
4mm (22-26) (19-22) (23-27)
6mm (45-50) (38-43) (72-78)
8mm 12-Nov 9-10 14-16
10mm 18-20 15-17 45-50 40-45 70-75
12mm 42-44 36-38 56-60 50-55 95-105
16mm 140-148
18mm 185-200
20mm 280-290
TORQUE SPECIFICATIONS
Generator FT*LB
Flex Plate to Flywheel 12-15
Generator Case to Bellhousing 60
1/2" Socket Head Cap Screws for Lifting Channel 126
1/2" Hex Head Screws for Lifting Channel 120
Genset Isolators 33
GENERATOR TORQUE SPECIFICATIONS
