Terex T25I and T45I Super Quiet Generator 47
Operating Instructions and Parts Manual
June 2006
REV A
ITEM # PART # DESCRIPTION QTY.
1 GCI120030 HAT CHANNEL, REAR 1
2 GCU120010 HAT CHANNEL, ENGINE 1
3 GCU100000 TANK, FUEL, 64 GAL 1
4 720420 RUBBER SHEET, 1/8 BLK (12 SQ. FT.) AR
5 GCU110000 BASE, CONTAINMENT 1
6 C90900601 PLUG, PIPE, 3" SQUARE HEAD 1
7 990210 WASHER, FLAT 1/2 18
8 991650 WASHER, LOCK 1/2 18
9 990810 SCREW, 1/2-13NCX1-1/2
10 C43200601 SENDER, FUEL LEVEL 1
11 GASKET (INCLUDED WITH ITEM #10) 1
12 SCREW (INCLUDED WITH ITEM #10) 5
13 831804 FUEL CAP 1
14 895371 VALVE, VACCUUM RELIEF 1
15 792750 CLAMP 7/16 TO 25/32 2
16 890790 HOSE FUEL, 1/4X1/2 200# (1 FT.) AR
17 C91001300 FITTING BARB, 3/8 NPT 1
18 C90200600 BARB 3/8 X1/4 NPT 2
19 C90200400 FITTING, PICKUP&RETURN 2
20 C91100300 NYLON TUBING (1 FT.) AR
21 C90200900 BARB, 3/4 X1/2 NPT 3
22 792750 CLAMP, 7/16 TO 25/32 2
23 897910 HOSE,OIL, 3/4" AR
24 C90800100 VALVE, BALL 1/2 1
