Terex T25I and T45I Super Quiet Generator 57
Operating Instructions and Parts Manual
June 2006
REV A
ITEM # PART # DESCRIPTION QTY.
1 GCU320000 CONTROL PAN ASSY 1
2 GCU300002 CONTROL PANEL 1
3 C42200500 POTENTIOMETER. VOLTAGE 1
4 682070 BREAKER, MINI 1P 15A 1
5 C42208400 SWITCH, TOGGLE SINGLE 1
6 C43100800 GAUGE, DC VOLT 1
7 C43200400 GAUGE, OIL PRESSURE 1
8 260360 HOURMETER, 12V DC 1
9 C43200300 GAUGE, WATER TEMP 12V 1
10 C43200600 GAUGE, FUEL W/BLACK 1
11 261341 CASCADE CONTROLLER 1
12 INCLUDED WITH ITEM 11 4
13 C43100600 METER, VOLT DUAL 1
14 C43100400 METER, FREQUENCY 1
15 C43100500 METER, AMP 0-100 W/ 1
16 R980195 SCREW, 1/4-20NCX3/4 2
17 990340 WASHER, FLAT 1/4 8
18 992040 RIVET, POP 3/16X.602 10
19 CB45A112 HARNESS, AC CTRL/PNL 1
20 CU45A100 HARNESS, CTRL UNIVERSAL 1
21 C51600800 NUT, CLIP 1/4 -20X3/4 4
22 GCU320100 PLASTIC, ABS 1/8 X 10.5 X 22.5 1
23 C51200201 HINGE, PIANO 9 SS 2
24 C42401700 RELAY, OVER CURRENT 1
25 686735 RAIL, RELAY MOUNTING AR
26 SA465 OR SX460 AVR - CHECK UNIT BEFORE ORDERING PART 1
27 C42404000 TERMINAL STRIP, 6 POS 1
28 R660115 JUMPER, TERMINAL STRIP 2
29 CDWV40150 RELAY, 50A BOSCH 3
30 CDWV40151 RELAY, BASE 50A BOSCH 3
31 CDWV40152 RELAY, PIN 12
32 853813 DECAL, KIT RECEPTACLES AND BREAKERS 1
33 853838 DECAL, KIT CONTROL PANEL CASCADE 1
