Terex T25 - Page 59

Terex T25I and T45I Super Quiet Generator 59
Operating Instructions and Parts Manual
June 2006
REV A
ITEM # PART # DESCRIPTION QTY.
1 GCU320000 CONTROL PANEL ASSEMBLY 1
2 GCU300000 PANEL, 1PHASE 1
3 C42104500 BREAKER,70A SHUNTTRIP, T25I 1
3 C42104800 BREAKER,150A,SHUNTTRIP, T45I 1
4 685880 BREAKER, 2POLE 1PH 45A, T25I 1
4 685930 BREAKER, 2POLE 1PH 90A, T45I 1
5 C42103400 BREAKER, 20A 120/240V 2
6 C42103600 BREAKER, 50A 120/240V 2
7 684640 RECEPTACLE, 20A 120V 2
8 C42500100 TRANSFORMER, 100:5 3
9 C42500100 TRANSFORMER, 100:5, T25I 1
9 C42500200 TRANSFORMER,200:5, T45I 1
10 CU41S030 TEMP, POWER SLOPE 1
11 C47100300 RECEPTACLE, TWISTLOCK, 50A 2
12 R980195 SCREW, 1/4-20NCX3/4 4
13 990340 WASHER, FLAT 1/4 8
14 CU45A010 HARNESS, AC/GEN 1
15 C51601442 SCREW, FLANGE 1/4 -20 X 3/4 PATCH 4
16 C51601441 NUT, FLANGE, 1/4"-20 Z 4
17 990340 WASHER, FLAT 1/4 8
18 990340 WASHER, FLAT 1/4 8
19 853752 DECAL, REMOTE START 1
20 853813 DECAL, KIT RECEPTACLES AND BREAKERS 1
21 66812 E-STOP PUSHBUTTON 1
22 686662 E-STOP LABEL PLATE 1
23 66817 E-STOP CONTACT (N.C.) 1
24 671278 REMOTE START CONTACT 1
