Terex TR60 - Page 17

Section 100-0010
5
SM 1570 12-98
Chassis - Chassis, Hood and Fenders
1 - Radiator Guard
2 - Cover Plate
3 - Washer
4 - Bolt
5 - Bolt
6 - Nut
7 - Bolt
8 - Grille
9 - Bolt
Fig. 5 - Radiator Guard and Mounting
* * * *
SM - 1961
10 - Bracket
11 - Bolt
12 - Hardened Washer
13 - Plate
11
12
5
12
12
6
11
10
13
7
12
6
12
12
9
1
8
2
3
4
