Tesco KS14021 - Components Supplied

Components supplied (not actual size)
Ref Description Visual Qty
1 Lid assembly 1
2 Chimney 1
3
Temperature
gauge
1
4 Handle 2
5 Firebowl left panel 1
6
Firebowl front
panel
1
7
Firebowl back
panel
1
8
Firebowl right
panel
1
9 Warming rack 1
10 Cooking grill 2
11 Charcoal tray 1
12
Crank handle
threaded mount
1
13 Crank handle 1
14 Cart left assembly 1
15 Leg cap 2
16 Bottom shelf 1
17
Cart right
assembly
1
Ref Description Visual Qty
18 Wheel 2
19 Axle 1
20 Cart back support 1
21 Bottle opener 1
22 Firebowl front door 1
23 Ash tray handle 1
24 Ash tray 1
25 Damper 2
26
Side shelf front
bracket
1
27
Side shelf back
bracket
1
28 Hook 4
29 Side shelf 1
30 Lower hinge 2
31 Upper hinge 2
Components supplied (not actual size)
7
Produced in China for TESCO Stores Ltd.
Tesco 2017
www.tesco.com
American Charcoal Grill
Assembly instructions
