18
3.2.1 MEASUREMENTS menu
All mesasured values of the UPS can be monitored from this menu.
Use up and down buttons to move on submenu
MEASUREMENTS / INPUT (Level 2)
All rectifier input measurements are located in this menu, use up and down buttons to move on submenu
(Level 2)
P-N L1 L2 L3 Page header
V: 221/222/223 V Phase to neutral measured AC input voltages
I: 000/000/000 A Measured RMS AC input phase currents
P-P L1-3 L2-1 L3-2 Page header
V: 381/382/383 V Phase to phase measured AC input voltages
FREQ: 49.6 Hz Measured rectifier input frequency
MEASUREMENTS / BYPASS (Level 2)
All by-pass input measurements are located in this menu, use up and down buttons to move on submenu
(Level 2)
P-N L1 L2 L3 Page header
V: 221/222/223 V Phase to neutral measured AC bypass input voltages
OK OK -- Bypass voltage status
P-P L1-3 L2-1 L3-2
Page header
V: 381/382/383 V Phase to phase measured AC bypass input voltages
FREQ: 50.0 / OK Hz Measured bypass input frequency
MEASUREMENTS / INVERTER MENU (Level 2)
All inverter measurements are located in this menu, use up and down buttons to move on submenu
(Level 2)
P-N L1 L2 L3 Page header
V: 221/222/223 V Phase to neutral measured AC Inverter output voltages
FREQ: 50.0 Hz Measured Inverter output frequency
MEASUREMENTS / OUTPUT MENU (Level 2)
All UPS output measurements are located in this menu, use up and down buttons to move on submenu
Page 1 (Level 2)
P-N L1 L2 L3 Page header
V: 221/222/223 V Phase to neutral measured AC UPS output voltages
I: 00.0/00.0/00.0 A Measured AC RMS load currents
P-P L1-3 L2-1 L3-2 Page header
V: 381/382/383 V Phase to phase measured AC UPS output voltages
FREQ: 50.0 Hz Measured UPS output frequency
Left previous page, right next page
Page 2 (Level 2)
L1 L2 L3 Page header
Load 000/000/000 % Measured load percentage
KW 000.0/000.0/000.0 Measured output watt power
KVA 000.0/000.0/000.0 Measured output KVA power
PF: ---- ---- ---- Load power factor
C.F: 0.0 / 0.0 / 0.0 Load crest factor
Left previous page, right next page
