MEASUREMENTS / DC MENU (Level 2)
All DC measurements are located in this menu, use up and down buttons to move on submenu
MEASUREMENTS
/
DC
(Level 2)
VBAT 405/-405 V Measured battery voltages
ICHRG 00.0/00.0 A Measured battery charge currents
IDSCHRG 00.0/00.0 A Measured battery discharge currents
BATTERIES : 30 x 2 Batteries in one group
PAR. BAT : 1 Parallel battery groups
BATT. A/H : 007 Ah Battery amper / hour rating
BACKUP TIME 0000 min Calculated remaining time
MEASUREMENTS / GENERAL MENU
Temperature measurements are located in this menu, use up and down buttons to move on submenu
MEASUREMENTS / GENERAL
(Level 2)
TH1: ---- C Measured external sensor temperature
TH2: 24.2 C Measured battery cabinet inside temperature
TH3: ---- C Measured internal sensor temperature
MEASUREMENTS / TEMPs MENU(ONLY IN DX 100-250)
IGBT internal temperatures can be monitored in this menu, these values are also used for overtemperature
protection.
MEASUREMENTS / GENERAL
(Level 2)
NTC0 Rectifier IGBT Temp. (U)
NTC1 Rectifier IGBT Temp. (V)
NTC2 Rectifier IGBT Temp. (W)
NTC3 Inverter IGBT Temp. (U)
NTC4 Inverter IGBT Temp. (V)
NTC5 Inverter IGBT Temp. (W)
3.2.2 ALARM LOGS MENU
Use this menu to see the alarm log records
ALARM
LOGS
Page 1
(
Level 1
)
>191>03.10.12 14:33:26 Event no ,date and time (up and down buttons move)
>000>07.12.12 16:58:26 Event no ,date and time (up and down buttons move)
>001>07.12.12 12:24:26 Event no ,date and time (up and down buttons move)
ALARM LOGS
Alarm Logs
- - - PRESS & HOLD ENTER FOR 3 SEC TO CLEAR LOGS - - -
3.2.3 INFORMATION MENU
Some usefull informations are located in this menu , use up and down buttons to move on submenu
INFORMATION MENU
Page 1
(
Level
1
)
RS232 COMM: 1:-- RS232 activity indicator for com1
RS232 COMM: 2:-- RS232 activity indicator for com2
MAX POWER (VA): 60000 Maximum ups output power as VA
NOMINAL VALUE:220/050 220/050 Nominal input, output voltage and frequency
INV VERSION: 00001 Inverter module firmware version
PFC VERSION: 00001 PFC rectifier module firmware version
LCD VERSION: 00001 Front panel modul firmware version
MODEL: DXA3000 Model name of the UPS
Up previous page, down next page
