20
Page 2
Protocol:TX301 Communication protocol version
Chassis nr: 123456 UPS chassis nr
Up previous page, down next page
3.2.4 OPTIONS MENU
Use up and down buttons to move cursor on submenu at the end of page you move to next page. Menu
has 3 level structure, if user password is enabled some parameters requires user password.
Level 2 LCD panel options group
Panel language selection Page1
Button click ON/OFF Page1
LCD backlight brigthness Page1
Backlight delay Page1
Backlight dim.delay Page1
ENTER - EXIT Page1
Page 1 (Level 1)
LANGUAGE:ENGLISH Press enter to select
change panel language
CLICK: ON/OFF Press enter to select
buton click sound ON/OFF
BACKLIGHT: 08 Press enter to select
LCD backlight brightness adjust
BL DELAY:CLOSED Backlight delay
BL DIM:CLOSED Back light half option selection
ENTER - EXIT ENTER exit to upper menu
Up upper line, down next line ,(+) or (-) options ,ENTER select an option
Level 2 – Communication options
Remote control ON/OFF Page1
COM2 port function Page1
SNMP internal/external Page1
REPO input ON/OFF Page1
RELAY-ALARM ASSIGN Page1
GENIN: LOCIG-0 Page2
EPO: LOCIG-0 Page2
RELAY CONTACTS:NO Page2
ENTER - EXIT Page2
OPTIONS / COMMUNICATION OPTIONS
Page 1 (Level 2)
REMOTE CNTRL: ON/OFF Press enter to select
remote control ON/OFF
COM2:SERVICE PORT Com 2 serial port function selection
SNMP : INTERNAL/EXTERNAL SNMP adaptor location
REPO : ON / OFF Emergency stop input enabled or disabled
RELAY-ALARM ASSIGN Press enter to assign alarm
ENTER - EXIT ENTER exit to upper menu
Up upper line, down next line ,(+) or (-) options, ENTER select an option
To Next Page
