24
REC CODE = XXXX XXXX SYSTEM fault occured at the rectifer module
R00 REC FAULT = XXXX Fault Rectifier AC input voltage is high
CALL SERVICE !
R01 AC INPUT HIGH Alarm Rectifier AC input voltage is low
R02 LINE FAILURE Alarm Rectifier DC output voltage is high
R03 DC BUS HIGH Alarm The rectifier DC output voltage is high, rectifier stop
R05 FREQ TOLER Alarm Rectifier input frequcny out of tolerant
R06 OVERTEMPERATURE Alarm Rectifier heatsink temperature high
R07 BLACKOUT Alarm Short voltage blackout at rectifier AC input
R08 I/P OVERCURRENT Alarm Rectifier IGBT saturation alarm
R09 ROTATE PHASE Alarm Rectifier input phase sequency incorrect
R14 PFC MANUAL STOP Alarm Inverter module stopped rectifier
R15 DC LOW Alarm DC BUS voltage is lower then DC rectifier start voltage
R17 BATTERY TEST Warning
Currently battery test is performing
R18 BOOST CHARGE Warning
Currently rectifier is in boost charge mode
R19 AC HIGH Alarm AC Peak voltage is bigger then 20% of nominal range
R20 INPUT CB OPEN Warning
Input CB is off
R21 PFC STOP Warning
Currently Rectifier module stop
R22 POS CHG LIMIT Warning
(+)Battery charge current limited
R23 NEG CHG LIMIT Warning
(-)Battery charge current limited
R24 WAITING DC BUS Warning
Rectifier is waiting DC BUS to raise for startup
R25 BATTERY FAILURE Warning
Battery test failed
R26 BATT TEMP SENSOR Warning
Battery temperature sensor is defected or not connected
R27 BATT TEMP HIGH Warning
Battery ambient temperature is high
R29 PFC RESET Warning
Rectifier module power on
R30 PLEASE WAIT Warning
Rectifier waits as adjusted startup delay
R31 RECTIFIER START Warning
Rectifier is in soft start stage
L01 TH1 TEMP HIGH Warning
TH1 temperature is high
L02 TH2 TEMP HIGH Warning
TH2 temperature is high
L03 TH1 TEMP LOW Warning
TH1 temperature is low
L04 TH2 TEMP LOW Warning
TH2 temperature is low
L05 FAN MAINT Warning
FAN maintenance time
L06 BATTERY MAINT Warning
Battery maintenance time
L07 OPT MAINTENANCE Warning
Optional maintenance time
L08 TH1 SENSOR FAIL Warning
TH1 temperature sensor failure
L09 TH2 SENSOR FAIL Warning
TH2 temperature sensor failure
L10 ENTER FAULT RESET Warning
UPS is waiting fault reset for startup
L11 BATT CB OPEN Warning
External interactive battery switch is off
L12 GENERAL MAINT Warning
General maintenance time
L13 PFC CAN COMM ERR Warning
PFC module CAN communication timeout
L14 INV CAN COMM ERR Warning
INV module CAN communication timeout
Inverter module alarm codes
INV CODE = 0XXX Current inverter modüle status code
A00 INV FAULT = XXXX Hata XXXX fault occured at the inverter module
CALL SERVICE !
A01 O/P OVERCURRENT Alarm IGBT saturation alarm on inverter module
A02 OVERTEMP SHUT Alarm Overtemperature at inverter power module
A03 BATT HIGH Alarm Inverter module measured battery voltage high
A04 OUTPUT V.LOW Alarm Inverter output voltage is low
A05 OUTPUT V.HIGH Alarm Inverter output voltage is high
A06 OVERLOAD SHUT Alarm Overload at UPS output
A07 SHORT CIRCUIT Alarm Short circuit at UPS output
